Yanmar Conventional Tail (Standardan) SV26
radna težina 2740 kg
širina (mm) 1550 mm
dubina kopanja (mm) 2595 - 2845 mm
transportna težina 2525 kg (canopy) / 2665 kg (cabin)
tip motora 3TNV82A-BPBVA
gorivo Diesel
neto snaga 17.6 kW / 23.9 HP / 2400 rpm
bruto snaga 18.1 kW / 24.8 HP / 2400 rpm
max obrtni moment 85.5 N.m. / 1400 rpm
maksimalni pritisak 210 bars
katalog PDF katalog
Discover first-class performance in a surprisingly compact package, perfect for urban work and landscaping, even in the most challenging of environments. Excellent stability and low ground pressure ensures efficiency on all types of terrain while decreasing soil degradation. The largest cab in its class and clever design delivers real operator comfort, while an advanced hydraulic system offers fast performance with real control. A complete protection system boosts durability, and fuel consumption is remarkably low as well.
STABILITY The SV26 benefits from a conventional structure with reduced tail overhang, which gives it increased lifting performance and stability in even the most challenging of work environments. In addition, a long track base adds to digging stability and lifting capacity, while the wide 300 mm tracks give excellent traction. An additional rear counterweight of 100 kg is available as an option, protecting against possible shocks and friction against walls when using heavy attachments such as a tiltrotator. COMFORT This excavator boasts the largest cab in its class, the spacious interior and generous legroom allowing for maximum freedom of movement and ensuring more comfort and less fatigue for the operator. The entrance is correspondingly large as well, providing easy cab access and exit. A lot of thought has gone into the interior architecture and operator positioning. All controls are placed to the right hand side for easy access, while a digital panel provides operator and maintenance overviews.
